Swargandh

Below Plinth Level - Anti termite Treatment, Filling, Soling, PCC. Above Plinth Level - Column, Beam, Paradi, Machine romm, Lift. RCC Roof Slab Should be Treated with water proofing. RCC Loft of 1-1/2' Width to be Provided in Kitchen & Bedroom. Earthquake Resistance RCC Structure as Per in Code-M20 concrete.

External and Internal Brick Wall 6 inches and 4-1/2 inches Thick-Chicken Mesh for joint sealing Externl 15/25MM Sand Faced Double Coat Plaster. Internal 15MM Thick Neeru Finished Cement Plaster. Terrace Waterfroofing in Brick Bat type with PVC Rainwater Downtake Pipe. Bath Totlets Brick Bath Waterproofing with Spout. Chemical Waterproofing in Toilets. Basecoat in each Toilet and Dry Terrace.

Living room, kitchen and passage flooring � italian marble or vitrified tiles of 24 by 24 inches � kajaria / johnson / nitco Bedroom � vitrified tiles � johnson / nitco / kajaria of 18 by 18 inches Toilets and balconies � anti skid tiles - johnson / nitco / kajaria of 12 by 12 inches Dado � full height � colored glazed tiles - johnson / kajaria 8 by 12 inches or 8 by 8 inches Steps � 4 ft wide kota stone single piece treads & risers in vitrified tiles. Landing � non slippery ceramic tiles of matching color or kota flooring

L- shaped 10 ft long black granite kitchen platform with deep ss sink(nirali) of size 8 inches by 21 inches johnson / kajaria Full height dado 8 inches by 12 inches johnson / kajaria Below kitchen otta 2nd quality ceramic tiles dado Provision for water purifier, refrigerator, chimney or exhaust fan Main door � teak wood frame 6 inches by 2.5 inches width decorative flush door Shutter with magic eye, safety chain, tower bolt, brass fitting vertibolt night latch of godrej /europa or dead lock All other door frame � teak wood frame (4 inches by 2.5 inches) with laminated flush door shutter Toilets � green marble door frame with phenol resin bonded water-proof shutter Shutters with louvers at down & frosted glass at upper side with full laminate sheet covering fron inside the shutter Open terrace � with sliding door with glass or m.s. openable door with glass Jindal aluminium medium section powder coated sliding windows of three track with mosquito net arrangement M.S. safety grill of 10 sq. mm. bars Green marble window sills

Connected wiring through concealed / pvc casing of modi make Distribution box with mcb Switches and sockets of ns / roma modular type In common terrace at the top 4 lp In living room � 2 lp, 1 bp, 1 plug point, 1 fp In bed room � 2 lp, 1 fp, 2 plug point ( 1 for night lamp & 1 for mosquito mat) In bath / toilet � 1 lp, 1 power point In passage / basin � 1 lp In w.c. - 1 lp In kitchen � 2 lp, 1 fp, 1 power point, 1 plug point In balcony / terrace � 1 lp Phone and t.v. connection in bedroom and living room to each flat Copper earthing at every flat connected to common earth rit at ground Drainage chember and pipes as per p.m.c. rules

External plumbing will be in gi fitting and pipes All downtake and rain pipes and pvc of required sizes All internal plumbing will be in �c� class or pvc pipe. Internal plumbing will be of concealed pipe with proper jointing using chemicals Toilet fitting � all cp fittings � jaquar continental make Concealed plumbing in toilets. premium quality plumbing and sanitary fittings with orissa pan with half turn cock in common toilet In attached toilet � e.w. commode arrangement with jet spray One wash basin in attached toilet Hot and cold water mixer for the baths One wash basin � suitable size � should be coloured one of parryware / hindustan / nycer in passage area Dry balcony � with small washing place. plumbing provision for washing machine.additional bore tap. One wash basin in common terrace (top terrace) Lpg geyser provision

Painting to all internal wall will be oil bond distemper External including compound wall will be finished in specified water proof Cement paint of standard company All doors will be enamel painted with nerolac or asian paints Enamal paint to safety grills
